Girder Clamp - Black 3.2T

Clamp

Adjustable all-steel beam clamp rated to 3.2 tonnes, its jaw taking 80 to 345 mm flanges to make a fixed pick point on venue steel, proof-tested to 150 percent and serial-numbered with its cert. Hire across SEQ.

Working Load Limit	3.2 t
Flange Range	80 – 345 mm
Proof Load	150% of WLL, factory tested
Standards	AS 4991:2004
Traceability	Individually serial-numbered with test certificate
Material	All-steel, black powder-coat finish
Use	Fixed suspension / lifting point on steel beams and girders

Overview

About the Girder Clamp - Black 3.2T

The Black 3.2T Girder Clamp is an adjustable all-steel beam clamp that bolts onto a steel I-beam or girder to create a rated fixed suspension point. Its screw-adjusted jaw takes flange widths from 80 mm to 345 mm, covering the venue steelwork found in exhibition halls, warehouses and sports centres.

Typical applications

Chain hoist pick points on venue steel where no rigging points exist
Suspending truss, audio and lighting from exposed beams
Temporary lifting and pulling points for installs and bump-ins

Rated, tested, traceable

Rated to 3.2 tonnes WLL and proof-load tested to 150% of capacity, the clamp complies with AS 4991 and ships individually serial-numbered with its test certificate: the paperwork venue riggers and safety officers ask for. The black powder-coat finish keeps it discreet against dark steelwork. Pairs with our Universal Beam Clamp for lighter-duty points.

Hire it for your next show

The Girder Clamp - Black 3.2T is part of the Krank’d rigging inventory, available across the Gold Coast, Brisbane, and Australia-wide. We supply, rig, and operate. Your event, our show.
