Astera Titan Tube 8-Way Kit

Effect IP Rated

Eight Astera AX1 Titan Tubes in a wheeled case with a built-in PowerBox that recharges every tube in place from one PowerCON TRUE1 feed. Wireless pixel tubes, hire-ready across SEQ.

Kit Contents	8× AX1 Titan Tubes, PowerBox, 16× truss holders & eyebolts, 8× floor stands, cables
Charging Case	Wheeled hard case that charges all 8 tubes inside
Power Input	1× PowerCON TRUE1 for the full case
LED Type (per tube)	RGBMintAmber (RGBMA)
LED Wattage (per tube)	48W
Battery Runtime	Up to 20 hours per tube
Control Protocols	Wired DMX, Wireless CRMX (LumenRadio), Bluetooth (AsteraApp)
IP Rating	IP65
Tube Dimensions	Ø42 mm × 1035 mm
Tube Weight	1.35 kg

Downloads Spec Sheet (PDF) DMX Chart (PDF) GDTF Fixture File

Overview

About the Astera Titan Tube 8-Way Kit

The Titan Tube 8-Way Kit is the full wireless pixel-tube package: eight Astera AX1 Titan Tubes in a wheeled hard case with a built-in PowerBox that recharges every tube while it travels. Plug one PowerCON TRUE1 feed into the case and all eight tubes charge in place. The rig rolls in ready and rolls out the same way.

What’s in the case

8× AX1 Titan Tube
1× PowerBox that charges the tubes inside the case
16× eyebolts and 16× truss holders with cotter pins
16× ¼″ babypins for stand and grip mounting
8× tube floor stands
PowerCON TRUE1 cable, 8× DC charging cables and waterproof port covers

One case, every position

The included hardware covers the three ways tubes get used on real shows: flown on truss with the holders, standing on the floor stands, or rigged on grip gear via the babypins. Each tube runs up to 20 hours on battery with full CRMX, wired DMX, Bluetooth and pixel-mode control, and the IP65 rating keeps the whole kit working outdoors.

Hire it for your next show

The Titan Tube 8-Way Kit is part of the Krank’d battery-powered inventory, available across the Gold Coast, Brisbane, and Australia-wide. We supply, rig, and operate. Your event, our show.
