RC4 Wireless 4DimM4

Interface

Hire the RC4 LumenDimM4: 4-channel wireless CRMX dimmer, 5A per channel, for LEDs & props. Wireless dimming hire in Gold Coast & Brisbane.

Protocol	DMX512, LumenRadio CRMX
Channels	4-channel dimmer
Voltage Range	6V – 35V DC
Max Current Per Channel	5A per channel (20A total)
PWM Frequency	Up to 20kHz
Operating Temperature	-20°C to 50°C
Dimensions	95 × 60 × 23 mm
Weight	120 g

Overview

About the RC4 Wireless 4DimM4

The RC4 Wireless 4DimM4 is a compact, 4-channel wireless DMX dimmer engineered for low-voltage DC applications. Built around LumenRadio’s CRMX wireless DMX technology, widely regarded as the industry benchmark for reliable wireless control, the 4DimM4 delivers rock-solid, interference-resistant communication without the need for data cabling. At just 120 g and measuring 95 × 60 × 23 mm, it is purpose-built for integration into props, set pieces, costumes, architectural elements, and any application where running DMX cable is impractical or impossible.

Performance & Technical Detail

Each of the four independent output channels handles up to 5A, providing a combined 20A total load capacity across the unit. The wide input voltage range of 6V to 35V DC makes the 4DimM4 compatible with a broad variety of LED tape, LED fixtures, incandescent lamps, motors, and other DC-driven devices commonly found in live production and themed environments. PWM output frequency reaches up to 20 kHz, ensuring genuinely flicker-free dimming, a critical requirement for film and television work where camera frame rates and shutter angles can expose low-frequency PWM artefacts. An operating temperature range of -20°C to 50°C means the unit performs reliably across both climate-controlled studios and demanding outdoor event environments.

Production Use Cases

The 4DimM4 is a go-to solution for productions requiring discrete, wireless-controlled practical lighting. Typical applications include LED-lit set dressing and scenic elements, wireless control of practicals in theatre and live performance, battery-powered costume lighting for touring productions, and on-set lighting control for broadcast and film where cable runs are restricted. Its PCB mounting holes and compact enclosure allow it to be permanently integrated into custom builds or quickly deployed as a standalone unit on hire.

Hire the RC4 Wireless 4DimM4 in Gold Coast & Brisbane

The RC4 Wireless 4DimM4 is available for hire from Krank’d Productions, servicing the Gold Coast, Brisbane, and surrounding South East Queensland regions. Whether you’re working on a touring concert, theatrical production, film shoot, or corporate event requiring wireless practical control, our team can advise on integration with your existing DMX and CRMX infrastructure. Contact us for availability, pricing, and technical support.
