Global F34 - Top Plate

About the Global F34 – Top Plate

The Global F34 Top Plate (SQ-4137) is a 305 × 305mm (12″ × 12″) aluminium plate that serves as the interface between F34 truss segments and ground support systems or fixed structural points. Used at the base of freestanding truss towers, it distributes load across the floor surface and provides a stable, flat footing. When inverted and used at the top of a vertical run, it acts as a ceiling attachment or load transfer plate.

At 5mm thick and machined from aluminium, the plate is lightweight enough to add minimal overhead to a rig inventory while providing the structural connection required for safe, load-rated assemblies. Compatible with the full F34 system via standard conical coupler and M12 bolt connection.

Typical Applications

• Base plate for freestanding F34 lighting towers
• Load transfer plate at the top of vertical truss stacks
• Ceiling interface for hanging truss grids
• Ground support foot plate in conjunction with outrigger legs

The Global F34 square truss system is a professional-grade 4-point box truss engineered for the live events, touring, theatre, and broadcast industries. Built from EN-AW 6082 T6 aluminium alloy (the same specification used in aerospace structural applications), the F34 delivers exceptional strength-to-weight ratio and long-term corrosion resistance.

Why the F34?

The F34’s 290mm × 290mm cross-section provides outstanding rigidity under load, making it ideal for lighting rigs, audio flown systems, staging canopies, and truss arch installations. Each segment connects via precision-machined conical couplers and M12 bolts, creating a secure, repeatable joint that can be assembled and dismantled hundreds of times without wear to the connection points.

Safety & Certification

Global’s F34 series is designed and tested to comply with EN 13814, the European standard for fairground and amusement structures. Every component in this system is manufactured under ISO 9001-certified quality management, ensuring consistent performance across the product range.

Compatibility

All F34 components, including straight segments, corners, rings, and base plates, are fully interoperable within the F34 system. The 290mm profile is also compatible with a wide range of industry-standard clamps, coupler plates, and motor attachment hardware.
